LT5527EUF
RoHS
/
Package 16-WQFN Exposed Pad
Category RF/IF and RFID / RF Mixers
Description
IC MIXER 400MHZ-3.7GHZ DWN 16QFN
PDF
/
Buying Options
Total Price: USD $7.29
Unit Price: USD $7.2864
≥1 USD $7.2864
Inventory: 1634
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-WQFN Exposed Pad
Surface Mount YES
Technical
Published 2005
Series LT5527
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Voltage - Supply 4.5V~5.25V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 235
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Reach Compliance Code not_compliant
Frequency 400MHz~3.7GHz
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 16
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Temperature Grade INDUSTRIAL
Current - Supply 78mA
Gain 2.3dB
Telecom IC Type RF AND BASEBAND CIRCUIT
RF Type Cellular, GSM, MMDS, TD-SCDMA, UMTS, WCDMA
Secondary Attributes Down Converter
Noise Figure 12.5dB
Number of Mixers 1
Dimensions
Height Seated (Max) 0.8mm
Length 4mm
Width 4mm
Compliance
RoHS Status Non-RoHS Compliant
