TRF2443IPFP
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC IQ/IF TXRX DUAL-BAND 80HTQFP
PDF
/
Buying Options
Total Price: USD $54.03
Unit Price: USD $54.03125
≥1 USD $54.03125
≥10 USD $44.33365
≥100 USD $42.94855
≥500 USD $41.5625
≥1000 USD $40.1774
Inventory: 1163
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 12mm
Length 12mm
Height 1.2mm
Technical
RF Type WiMax
Telecom IC Type TELECOM CIRCUIT
Logic Function Transceiver
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3.3V
Function IF Transceiver
Base Part Number TRF2443
Frequency 140MHz~160MHz 280MHz~330MHz
Depth 12mm
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tray
Physical
Number of Pins 80
Package / Case 80-TQFP Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
