TRF1212IRGZT
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC PLL/VCO DUAL W/DWN CNV 48VQFN
PDF
/
Buying Options
Total Price: USD $23.82
Unit Price: USD $23.8165
≥1 USD $23.8165
≥10 USD $19.5415
≥100 USD $18.93065
≥500 USD $18.32075
≥1000 USD $17.7099
Inventory: 5009
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Technical
Input Power-Min (CW) 20dBm
Power Gain 100dB
Down Conversion Gain-Min 90 dB
LO Tunable YES
Noise Figure 5 dB
Secondary Attributes IF Downconversion
Characteristic Impedance 50Ohm
RF Type UHF, VHF
RF/Microwave Device Type DOWN CONVERTER
Nominal Supply Current 200mA
Power Supplies 5V
Operating Supply Voltage 5.2V
Function Dual VCO/PLL Synthesizer
Base Part Number TRF1212
Frequency 2.4GHz~3.55GHz
Construction COMPONENT
Max Power Dissipation 1.5W
Subcategory RF/Microwave Up/Down Converters
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 48
Surface Mount YES
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
