LMX2502LQ1635
RoHS
/
Package 28-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC FREQ SYNTH W/INT VCO 28WQFN
PDF
/
Buying Options
Total Price: USD $2.94
Unit Price: USD $2.9392
≥1 USD $2.9392
Inventory: 3083
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-WFQFN Exposed Pad
Surface Mount YES
Number of Pins 28
Technical
Packaging Tape & Reel (TR)
Series PLLatinum?
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Subcategory PLL or Frequency Synthesis Circuits
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.8V
Terminal Pitch 0.5mm
Frequency 1635MHz
Base Part Number LMX2502
Function Frequency Synthesizer
Operating Supply Voltage 2.8V
Temperature Grade OTHER
Number of Circuits 1
Max Supply Voltage 3.3V
Min Supply Voltage 2.7V
Nominal Supply Current 17mA
RF Type CDMA, PCS
Secondary Attributes Integrated PLL and VCO
Dimensions
Height Seated (Max) 0.8mm
Length 5mm
Width 5mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
