SE2603L-R
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
RF Front End 2.4GHz 802.11bgn 3.3Volt
PDF
/
Buying Options
Total Price: USD $7.84
Unit Price: USD $7.84415
≥1 USD $7.84415
≥10 USD $6.43625
≥100 USD $6.23485
≥500 USD $6.03345
≥1000 USD $5.833
Inventory: 34007
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Surface Mount YES
Weight 928.191737mg
Technical
Packaging Tape & Reel (TR)
Published 2012
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
Max Operating Temperature 85°C
Min Operating Temperature -30°C
HTS Code 8542.39.00.01
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.4mm
Reach Compliance Code unknown
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XQCC-N24
Function Front End
Operating Supply Voltage 3.3V
Temperature Grade OTHER
Operating Supply Current 180mA
Data Rate 11 Mbps
Telecom IC Type TELECOM CIRCUIT
RF Type 802.11b/g/n
Dimensions
Height Seated (Max) 0.9mm
Length 4mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
