MAX9989ETP
RoHS
/
Package 20-WQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Tube 20 LO Buffers 40dB Reverse Isolation RF IC 5mm 5V 700MHz~1.1GHz 85C
PDF
/
Inventory: 8003
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Secondary Attributes 40dB Reverse Isolation
RF Type Cellular, GSM
Telecom IC Type RF AND BASEBAND CIRCUIT
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status COMMERCIAL
Function LO Buffers
JESD-30 Code S-XQCC-N20
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 700MHz~1.1GHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 245
Terminal Form NO LEAD
Terminal Position QUAD
Technology BICMOS
Terminal Finish TIN LEAD
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Physical
Surface Mount YES
Package / Case 20-WQFN Exposed Pad
Mounting Type Surface Mount
