MAX2322EUP+ image
Favorite
MAX2322EUP+ image
Favorite
RoHS
RoHS RoHS compliant
Package 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description Tube Dual Band LNA/Mixer Surface Mount PCS RF IC 9.6dB 1.85GHz~1.91GHz 50Ohm 85C
PDF
/
Inventory: 910
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Noise Figure-Max 13.5 dB
Down Conversion Gain-Min 9.6 dB
LO Tunable YES
Characteristic Impedance 50Ohm
RF Type PCS
RF/Microwave Device Type DOWN CONVERTER
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function Dual Band LNA/Mixer
Frequency 1.85GHz~1.91GHz
Construction COMPONENT
Terminal Finish TIN
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Tube

Physical

Package / Case 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
