ADP3522ACP-3-REEL7
RoHS
/
Package /
Category RF/IF and RFID / RF Misc ICs and Modules
Description
1 32 POWER SUPPLY SUPPORT CIRCUIT Obsolete RF IC 5mm 3.6V 85C
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.0248
≥1 USD $5.0248
Inventory: 57086
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Technical
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Terminal Finish TIN LEAD
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 3.6V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 32
JESD-30 Code S-XQCC-N32
Operating Temperature (Max) 85°C
Operating Temperature (Min) -20°C
Supply Voltage-Max (Vsup) 5.5V
Temperature Grade OTHER
Supply Voltage-Min (Vsup) 3V
Number of Channels 1
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Adjustable Threshold YES
Dimensions
Height Seated (Max) 1mm
Length 5mm
Width 5mm
Compliance
RoHS Status Non-RoHS Compliant
