AD630KN
RoHS
/
Package 20-DIP (0.300, 7.62mm)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Tube 20 Modulator/Demodulator Through Hole RF IC 24.51mm 16.5V 2MHz 70C
PDF
/
Buying Options
Total Price: USD $27.92
Unit Price: USD $27.9224
≥1 USD $27.9224
Inventory: 225
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 24.51mm
Height Seated (Max) 4.57mm
Technical
Consumer IC Type CONSUMER CIRCUIT
Supply Voltage-Min (Vsup) 5V
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 16.5V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
Function Modulator/Demodulator
JESD-30 Code R-PDIP-T20
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Frequency 2MHz
Terminal Pitch 2.54mm
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Position DUAL
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code 5A991.B
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Physical
Surface Mount NO
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
