AD630JN
RoHS
/
Package 20-DIP (0.300, 7.62mm)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
BALANCED MODULATOR/DEMODULATOR
PDF
/
Buying Options
Total Price: USD $33.85
Unit Price: USD $33.8523
≥1 USD $33.8523
≥10 USD $27.7761
≥100 USD $26.90875
≥500 USD $26.04045
≥1000 USD $25.17215
Inventory: 7507
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code 5A991.B
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8542.39.00.01
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Pitch 2.54mm
Frequency 2MHz
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
JESD-30 Code R-PDIP-T20
Function Modulator/Demodulator
Qualification Status Not Qualified
Operating Temperature (Max) 70°C
Supply Voltage-Max (Vsup) 16.5V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 5V
Consumer IC Type CONSUMER CIRCUIT
Dimensions
Height Seated (Max) 4.57mm
Length 24.51mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
