TCP-3056N-QT
RoHS
/
Package 6-VFDFN
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Tape & Reel (TR) 6 Tuner Surface Mount RF IC 1mm 700MHz~2.4GHz 85C
PDF
/
Inventory: 9268
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 1.2mm
Height Seated (Max) 1mm
Technical
Telecom IC Type TELECOM CIRCUIT
Temperature Grade OTHER
Operating Temperature (Min) -30°C
Operating Temperature (Max) 85°C
Function Tuner
Frequency 700MHz~2.4GHz
Terminal Pitch 0.5mm
Terminal Form NO LEAD
Terminal Position QUAD
HTS Code 8542.39.00.01
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
Published 2014
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Surface Mount YES
Package / Case 6-VFDFN
Mounting Type Surface Mount
