MC1496DR2G
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
ON SEMICONDUCTOR - MC1496DR2G - KOMMUNIKATIONS-IC
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9944
≥1 USD $0.9944
≥10 USD $0.89144
≥100 USD $0.84656
≥500 USD $0.695288
≥1000 USD $0.649898
≥3000 USD $0.574341
Inventory: 1363
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 14
Weight 338.011364mg
Technical
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Max Operating Temperature 70°C
Min Operating Temperature 0°C
HTS Code 8542.39.00.01
Max Power Dissipation 33mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Terminal Pitch 1.27mm
Frequency 300MHz
Time@Peak Reflow Temperature-Max (s) 40
Function Modulator/Demodulator
Operating Supply Voltage 12V
Temperature Grade COMMERCIAL
Max Supply Voltage 30V
Operating Supply Current 5mA
Power Dissipation 33mW
Max Supply Current 5mA
Halogen Free Halogen Free
Consumer IC Type CONSUMER CIRCUIT
RF Type FM
Dimensions
Height 1.5mm
Length 8.75mm
Width 4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
