MC1496DR2
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Cut Tape (CT) 14 Modulator/Demodulator Surface Mount RF IC 8.65mm 12V 33mW 300MHz
PDF
/
Buying Options
Total Price: USD $2.95
Unit Price: USD $2.95355
≥1 USD $2.95355
≥10 USD $2.42345
≥100 USD $2.34745
≥500 USD $2.2724
≥1000 USD $2.1964
Inventory: 21914
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
RF Type FM
Consumer IC Type CONSUMER CIRCUIT
Power Dissipation 33mW
Nominal Supply Current 5mA
Supply Voltage-Min (Vsup) 12V
Temperature Grade COMMERCIAL
Supply Voltage-Max (Vsup) 12V
Qualification Status Not Qualified
Function Modulator/Demodulator
Time@Peak Reflow Temperature-Max (s) 30
Frequency 300MHz
Reach Compliance Code not_compliant
Terminal Pitch 1.27mm
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 33mW
HTS Code 8542.39.00.01
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2006
Packaging Cut Tape (CT)
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 weeks ago)
