MAX9990ETP+
RoHS
RoHS compliant
RoHS compliantPackage 20-WQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC BUFFER LO 20-TQFN
PDF
/
Buying Options
Total Price: USD $8.34
Unit Price: USD $8.3424
≥1 USD $8.3424
≥10 USD $7.64544
≥100 USD $6.95039
Inventory: 190
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Secondary Attributes 40dB Reverse Isolation
RF Type UMTS, DCS, PCS
Telecom IC Type RF AND BASEBAND CIRCUIT
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function LO Buffers
JESD-30 Code S-XQCC-N20
Base Part Number MAX9990
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1.5GHz~2.2GHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Technology BICMOS
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Tube
Physical
Surface Mount YES
Package / Case 20-WQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
