MAX9989ETP+
RoHS
RoHS compliant
RoHS compliantPackage 20-WQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC BUFFER LO 20-TQFN
PDF
/
Buying Options
Total Price: USD $43.15
Unit Price: USD $43.149
≥1 USD $43.149
≥10 USD $35.4046
≥100 USD $34.29785
≥500 USD $33.19205
≥1000 USD $32.0853
Inventory: 2503
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-WQFN Exposed Pad
Surface Mount YES
Number of Pins 20
Technical
Packaging Tube
Published 2002
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code 5A991
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Technology BICMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 700MHz~1.1GHz
Base Part Number MAX9989
Function LO Buffers
Operating Supply Voltage 5.25V
Temperature Grade INDUSTRIAL
Nominal Supply Current 116mA
Telecom IC Type RF AND BASEBAND CIRCUIT
RF Type Cellular, GSM
Secondary Attributes 40dB Reverse Isolation
Noise Figure -170 dB
Dimensions
Height Seated (Max) 0.8mm
Length 5mm
Width 5mm
Thickness 750μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
