MAX8582ETB+
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Conv DC-DC Single Step Down 2.7V to 5.5V 10-Pin TDFN EP
PDF
/
Buying Options
Total Price: USD $4.39
Unit Price: USD $4.387712
≥1 USD $4.387712
≥200 USD $1.751409
≥500 USD $1.692328
≥1000 USD $1.663444
Inventory: 1410
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-WFDFN Exposed Pad
Number of Pins 10
Technical
Packaging Strip
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Frequency 1.5GHz
Function Converter
Number of Outputs 1
Efficiency 94 %
Output Voltage 5.5V
Max Output Current 600mA
Operating Supply Voltage 5.5V
Input Voltage-Nom 3.6V
Temperature Grade INDUSTRIAL
Analog IC - Other Type SWITCHING REGULATOR
Min Input Voltage 2.7V
Control Mode VOLTAGE-MODE
Max Input Voltage 5.5V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BUCK
RF Type WCDMA
Switching Frequency 1.5MHz
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
