MAX8581ETB+T
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC CONV 2.5MHZ CDMA 10-TDFN
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.75215
≥1 USD $2.75215
≥10 USD $2.25815
≥100 USD $2.18785
≥500 USD $2.11755
≥1000 USD $2.0463
Inventory: 1417
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-WFDFN Exposed Pad
Number of Pins 10
Technical
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Frequency 2.5MHz 1.5MHz
Base Part Number MAX8581
Function Downconverter
Number of Outputs 1
Efficiency 94 %
Output Voltage 5V
Output Type Adjustable
Max Output Current 600mA
Operating Supply Voltage 5.5V
Input Voltage-Nom 3.6V
Temperature Grade INDUSTRIAL
Analog IC - Other Type SWITCHING REGULATOR
Output Current 600mA
Min Input Voltage 2.7V
Control Mode VOLTAGE-MODE
Max Input Voltage 5.5V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BUCK
RF Type Cellular, CDMA
Secondary Attributes 60M Ω Bypass in TDFN
Switching Frequency 2.5MHz
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
