MAX2870ETJ+T
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
RF FRACT INTEGER N SYNTH VCO
PDF
/
Buying Options
Total Price: USD $83.71
Unit Price: USD $83.71115
≥1 USD $83.71115
≥10 USD $81.0958
≥100 USD $78.4795
≥500 USD $75.8632
≥1000 USD $68.01525
Inventory: 120
Minimum: 1
-
+
Technical Details
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
RF Type General Purpose
Analog IC - Other Type PHASE LOCKED LOOP
Supply Voltage-Min (Vsup) 3V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 3.6V
Function Fractional, Integer-N Synthesizer/ VCO
Base Part Number MAX2870
Frequency 23.5MHz~6GHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Position QUAD
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2012
Packaging Tape & Reel (TR)
Physical
Number of Pins 32
Package / Case 32-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
