MAX2750EUA
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC OSC VOLT CNTRL 8-UMAX
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1214
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Modulation Sensitivity 140 MHz/V
Phase Noise -125 dBc/Hz
Secondary Attributes On-Chip Tank Circuit
RF Type ISM
Control Voltage-Min 0.4V
Control Voltage-Max 2.4V
Output Power -3dBm
Supply Current-Max 17mA
Oscillator Type VOLTAGE CONTROLLED OSCILLATOR
Operating Temperature (Min) -40°C
Physical Dimension 3.05mm x 3.05mm x 1.1mm
Operating Temperature (Max) 85°C
Function VCO
Frequency 2.4GHz~2.5GHz
Reach Compliance Code not_compliant
Supply Voltage 3V
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series MAX2750
Published 2012
Packaging Tube
Physical
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Alternative Model
