MAX2620EUA
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Tube 1 MAX Surface Mount RF IC 3.05mm 5.25V 10MHz 85C
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 19767
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Packaging Tube
Published 2002
Series MAX
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.65mm
Frequency 10MHz
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 8
Temperature Grade INDUSTRIAL
Max Supply Voltage 5.25V
Min Supply Voltage 2.7V
Telecom IC Type RF AND BASEBAND CIRCUIT
Dimensions
Height 950μm
Length 3.05mm
Width 3.05mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
