MAX2395ETI+
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MOD WCDMA W/DRIVER 28-TQFN
PDF
/
Buying Options
Total Price: USD $5.45
Unit Price: USD $5.4473
≥1 USD $5.4473
≥10 USD $4.46975
≥100 USD $4.3301
≥500 USD $4.19045
≥1000 USD $4.0508
Inventory: 1617
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Secondary Attributes Quasi-Direct, with VGA and PA Driver
RF Type WCDMA
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function Modulator
JESD-30 Code S-XQCC-N28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1.92GHz~1.98GHz
Terminal Pitch 0.5mm
Supply Voltage 2.85V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code 5A991
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Tube
Physical
Surface Mount YES
Package / Case 28-WFQFN Exposed Pad
Mounting Type Surface Mount
