MAX2322EUP+T
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC LNA/MIXER SIGE ADJ 20TSSOP
PDF
/
Inventory: 3830
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn)
Min Operating Temperature -40°C
Subcategory RF/Microwave Up/Down Converters
Construction COMPONENT
Frequency 1.85GHz~1.91GHz
Function Dual Band LNA/Mixer
Power Supplies 3/3.3V
Supply Current-Max 30.8mA
RF/Microwave Device Type DOWN CONVERTER
RF Type PCS
Characteristic Impedance 50Ohm
LO Tunable YES
Down Conversion Gain-Min 9.6 dB
Noise Figure-Max 13.5 dB
Compliance
RoHS Status ROHS3 Compliant
