MAX2055EUP+TD
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC ADC DRVR/AMP VAR GAIN 20TSSOP
PDF
/
Buying Options
Total Price: USD $10.59
Unit Price: USD $10.5868
≥1 USD $10.5868
≥10 USD $8.6868
≥100 USD $8.4151
≥500 USD $8.14435
≥1000 USD $7.87265
Inventory: 1387
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 6.5mm
Height Seated (Max) 1.1mm
Technical
Secondary Attributes 40dBm Output IP3
RF Type Cellular, ATE, PHS/PAS
Telecom IC Type BASEBAND CIRCUIT
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function ADC Driver/Amplifier
JESD-30 Code R-PDSO-G20
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 30MHz~300MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 20-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
