MAX2046ETJ
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC VECTOR MULTIPLIERS 32TQFN
PDF
/
Buying Options
Total Price: USD $16.18
Unit Price: USD $16.179207
≥1 USD $16.179207
≥10 USD $15.263401
≥100 USD $14.399431
≥500 USD $13.584378
≥1000 USD $12.815455
Inventory: 1541
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Secondary Attributes 15dBm Input IP3
RF Type Cellular, DCS, GSM, PCS, UMTS
Telecom IC Type BASEBAND CIRCUIT
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function High-Gain Vector Multiplier
JESD-30 Code S-XQCC-N32
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1.74GHz~2.06GHz
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn85Pb15)
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2003
Packaging Tube
Physical
Surface Mount YES
Package / Case 32-WFQFN Exposed Pad
Mounting Type Surface Mount
