MAX2023ETX+
RoHS
RoHS compliant
RoHS compliantPackage 36-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MOD/DEMOD HI DYN RNG 36-TQFN
PDF
/
Buying Options
Total Price: USD $15.03
Unit Price: USD $15.0271
≥1 USD $15.0271
≥10 USD $12.33005
≥100 USD $11.9453
≥500 USD $11.5596
≥1000 USD $11.17485
Inventory: 1535
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6mm
Length 6mm
Height 750μm
Technical
Secondary Attributes Up/Down Converter
RF Type CDMA, EDGE, GSM, TDMA
Telecom IC Type TELECOM CIRCUIT
Supply Current-Max 0.345mA
Operating Supply Current 295mA
Temperature Grade INDUSTRIAL
Power Supplies 5V
Operating Supply Voltage 5.25V
Function Modulator/Demodulator
Base Part Number MAX2023
Frequency 1.5GHz~2.5GHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology BICMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code 5A991.B.1
Number of Terminations 36
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tube
Physical
Weight 92.589543mg
Number of Pins 36
Surface Mount YES
Package / Case 36-WFQFN Exposed Pad
Mounting Type Surface Mount
