MAX2021ETX+
RoHS
RoHS compliant
RoHS compliantPackage 36-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Tube MAX2021 Modulator/Demodulator Up/Down Converter RF IC 6.1mm 5.25V 1.355W 650MHz~1.2GHz
PDF
/
Buying Options
Total Price: USD $11.69
Unit Price: USD $11.6864
≥1 USD $11.6864
≥10 USD $10.73864
≥100 USD $10.293184
≥500 USD $9.069104
≥1000 USD $8.624035
≥3000 USD $8.067629
Inventory: 159
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-WFQFN Exposed Pad
Number of Pins 36
Weight 92.589543mg
Technical
Packaging Tube
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 36
ECCN Code 5A991.G
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Max Power Dissipation 1.355W
Technology BICMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 650MHz~1.2GHz
Base Part Number MAX2021
Function Modulator/Demodulator
Operating Supply Voltage 5.25V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Operating Supply Current 271mA
Nominal Supply Current 271mA
Max Supply Current 315mA
Telecom IC Type BASEBAND CIRCUIT
RF Type GSM, EDGE, CDMA
Secondary Attributes Up/Down Converter
Dimensions
Height 750μm
Length 6.1mm
Width 6.1mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
