MAX1005EEE+T

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 16-SSOP (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Misc ICs and Modules
Description IC UNDERSAMPLER IF 16-QSOP
PDF
/
Inventory: 7123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 3.9mm
Length 4.89mm
Height Seated (Max) 1.75mm

Technical

Secondary Attributes Parallel Logic Interface
RF Type PCS, PHS, WLL
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 2.7V
Temperature Grade INDUSTRIAL
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function IF Undersampler
JESD-30 Code R-PDSO-G16
Base Part Number MAX1005
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.635mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Analog ICs
HTS Code 8542.39.00.01
Terminal Finish TIN
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 1997
Packaging Tape & Reel (TR)

Physical

Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 6 Weeks
