MAPS-010144-TR0500
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
PHASE SHIFTER 4-BIT 2.3-3.8 GHZ
PDF
/
Buying Options
Total Price: USD $29.53
Unit Price: USD $29.5328
≥1 USD $29.5328
≥10 USD $27.26152
≥100 USD $24.989536
≥500 USD $23.096392
≥1000 USD $21.96047
Inventory: 1150
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Phase Shift-Max 360 deg
Insertion Loss (Max) 4.5 dB
Characteristic Impedance 50Ohm
Input Power-Max (CW) 25dBm
RF Type Radar
VSWR-Max 1.3
Function Phase Shifter
Frequency 2.3GHz~3.8GHz
Construction COMPONENT
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Tape & Reel (TR)
Physical
Weight 937.688827mg
Number of Pins 24
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
