MADRCC0004
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
DRIVER,PB-FREE VERSION OF DR65-0
PDF
/
Buying Options
Total Price: USD $5.83
Unit Price: USD $5.8344
≥1 USD $5.8344
≥10 USD $5.34688
≥100 USD $4.8609
≥500 USD $4.374823
≥1000 USD $4.279
Inventory: 1370
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Packaging Tube
Published 2009
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Matte Tin (Sn)
Subcategory Other Interface ICs
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
JESD-30 Code R-PDSO-G16
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 5.5V
Power Supplies +-5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 4.5V
Number of Bits 1
Output Polarity COMPLEMENTARY
Interface IC Type TTL TO GAAS TRANSLATOR
Negative Supply Voltage-Nom -5V
Output Latch or Register NONE
Delay-Max 50 ns
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
