LTC4558EUD
RoHS
/
Package 20-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC POWER MANAGEMENT
PDF
/
Inventory: 7614
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Secondary Attributes SIM and Smart Card Interface
RF Type Cellular, 3G, GSM
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 2.7V
Temperature Grade COMMERCIAL EXTENDED
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function Power Management, Signal Level Translation
JESD-30 Code S-PQCC-N20
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code not_compliant
Terminal Pitch 0.4mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 235
Terminal Form NO LEAD
Terminal Position QUAD
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Physical
Surface Mount YES
Package / Case 20-WFQFN Exposed Pad
Mounting Type Surface Mount
