BGT24MTR11E6327XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 32-PowerVFQFN
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MMIC 24GHZ TWIN IQ RX 32QFN
PDF
/
Buying Options
Total Price: USD $8.99
Unit Price: USD $8.98605
≥1 USD $8.98605
≥10 USD $7.3739
≥100 USD $7.14305
≥500 USD $6.91315
≥1000 USD $6.6823
Inventory: 1120
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-PowerVFQFN
Technical
Packaging Tape & Reel (TR)
Published 2012
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Max Operating Temperature 150°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Max Power Dissipation 750mW
Technology BIPOLAR
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 24GHz~26GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PQCC-N32
Function Transceiver
Operating Supply Voltage 3.3V
Temperature Grade INDUSTRIAL
Interface SPI
Max Supply Voltage 3.465V
Min Supply Voltage 3.135V
Nominal Supply Current 150mA
Gain 26 dB
Telecom IC Type TELECOM CIRCUIT
RF Type General Purpose
Max Junction Temperature (Tj) 150°C
Ambient Temperature Range High 105°C
Dimensions
Height 900μm
Length 5.5mm
Width 4.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
