ZLNB2016JA16TC

Diodes Incorporated
RoHS
RoHS RoHS compliant
Package 16-UFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description Tape & Reel (TR) 16 Voltage/Tone Detector Surface Mount RF IC 3mm 8V 2mA 85C
PDF
/
Inventory: 8212
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 3mm
Length 3mm
Height Seated (Max) 0.65mm

Technical

RF Type General Purpose
Operating Supply Current 2mA
Analog IC - Other Type ANALOG CIRCUIT
Min Supply Voltage 3V
Max Supply Voltage 8V
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Function Voltage/Tone Detector
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Published 2010
Packaging Tape & Reel (TR)

Physical

Number of Pins 16
Package / Case 16-UFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
