AMMP-6530-TR2
RoHS
/
Package 8-QFN
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MMIC REJECT MXR 5-30GHZ 8-SMD
PDF
/
Buying Options
Total Price: USD $40.27
Unit Price: USD $40.2724
≥1 USD $40.2724
≥10 USD $33.04385
≥100 USD $32.0112
≥500 USD $30.97855
≥1000 USD $29.9459
Inventory: 29
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-QFN
Technical
Packaging Tape & Reel (TR)
Published 2013
Series AMMP-6530
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 8
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -55°C
HTS Code 8542.39.00.01
Construction COMPONENT
Frequency 5GHz~30GHz
Function Mixer
Operating Supply Voltage -3V
Nominal Supply Current 0A
Bandwidth 30 GHz
RF/Microwave Device Type IMAGE REJECTION
RF Type ISM; DBS; VSAT; 802.16/WiMax; WLL; MMDS
Input Power-Max (CW) 25dBm
Characteristic Impedance 50Ohm
Noise Figure 10 dB
Power Gain -8dB
Dimensions
Length 5mm
Width 5mm
Thickness 1.9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
