CHF12545DBF500L
RoHS
RoHS compliant
RoHS compliantPackage Flat Box, Terminator
Category RF/IF and RFID / RF Misc ICs and Modules
Description
RES CHAS MNT 50 OHM 5% 500W
PDF
/
Inventory: 7553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 12.7mm
Length 31.75mm
Height 5.08mm
Technical
RF/Microwave Device Type RF/MICROWAVE TERMINATION
Lead/Base Style Tab
Function Power Module
Base Part Number CHF12545
Frequency 0Hz~1GHz
Max Power Dissipation 500W
Composition Thick Film
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Resistance 50Ohm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 5%
Series CHF
Published 2008
Packaging Tray
Physical
Housing Material Aluminium
Package / Case Flat Box, Terminator
Mounting Type Flange Mount
Supply Chain
Factory Lead Time 18 Weeks
