HMC942LP4E
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MULTIPLIER X2 ACTIVE 24-QFN
PDF
/
Buying Options
Total Price: USD $32.12
Unit Price: USD $32.12
≥1 USD $32.12
≥10 USD $29.96752
≥100 USD $28.711936
≥500 USD $26.020104
≥1000 USD $25.122803
Inventory: 252
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Secondary Attributes Active Frequency Multiplier
Characteristic Impedance 50Ohm
Input Power-Max (CW) 10dBm
RF Type General Purpose
RF/Microwave Device Type FREQUENCY DOUBLER
Min Supply Voltage 4V
Max Supply Voltage 4.5V
Function Frequency Multiplier
Base Part Number HMC942
Frequency 25GHz~31GHz
Construction COMPONENT
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Physical
Number of Pins 24
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Factory Lead Time 8 Weeks
