HMC705LP4E
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC DIVIDER HBT PROGR 24-QFN
PDF
/
Buying Options
Total Price: USD $79.24
Unit Price: USD $79.244
≥1 USD $79.244
≥10 USD $74.71904
≥100 USD $70.190912
≥500 USD $65.662344
Inventory: 261
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Number of Pins 24
Technical
Packaging Strip
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 100MHz~6.5GHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number HMC705
Function Frequency Divider
Qualification Status Not Qualified
Operating Supply Voltage 5V
Temperature Grade INDUSTRIAL
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Operating Supply Current 190mA
Telecom IC Type TELECOM CIRCUIT
Dimensions
Height Seated (Max) 1mm
Length 4mm
Width 4mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
