HMC705LP4
RoHS
/
Package 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Prescaler Divider, Prog, (N=1-17) 6.5 GHz
PDF
/
Buying Options
Total Price: USD $113.14
Unit Price: USD $113.1416
≥1 USD $113.1416
≥10 USD $107.78856
≥100 USD $105.495104
Inventory: 26
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 24
Weight 928.191737mg
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 235
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Reach Compliance Code not_compliant
Frequency 6.5GHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number HMC705
Pin Count 24
Qualification Status Not Qualified
Operating Supply Voltage 5V
Temperature Grade INDUSTRIAL
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Operating Supply Current 190mA
Telecom IC Type TELECOM CIRCUIT
Dimensions
Height Seated (Max) 1mm
Length 4mm
Width 4mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
