HMC584LP5
RoHS
/
Package 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
VCO Oscillators VCOw/ Fo/2 & Div/4, 12.5 - 13.9 GHz
PDF
/
Buying Options
Total Price: USD $53.7
Unit Price: USD $53.6959
≥1 USD $53.6959
≥10 USD $44.05815
≥100 USD $42.6816
≥500 USD $41.30505
≥1000 USD $39.92755
Inventory: 1125
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 5.1mm
Length 5.1mm
Height 1mm
Technical
Phase Noise -110 dBc/Hz
Secondary Attributes Divide by 4
RF Type General Purpose
Control Voltage-Min 2V
Control Voltage-Max 12V
Output Power 7dBm
Supply Current-Max 380mA
Oscillator Type VOLTAGE CONTROLLED OSCILLATOR
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Power Supplies 5V
Operating Supply Voltage 5V
Operating Frequency 13900MHz
Physical Dimension 5.1mm x 5.1mm x 1.0mm
Qualification Status Not Qualified
Function VCO
Base Part Number HMC584
Frequency 12.5GHz~13.9GHz
Reach Compliance Code not_compliant
Supply Voltage 5V
Technology GAAS
Subcategory Other Oscillators
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code 3A001.A.11.B
Termination SMD/SMT
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Packaging Strip
Physical
Number of Pins 32
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 10 Weeks
