HMC529LP5TR
RoHS
/
Package 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MMIC AMP VCO HBT 2OUT 32QFN
PDF
/
Buying Options
Total Price: USD $3305.86
Unit Price: USD $3305.863484
≥1 USD $3305.863484
≥10 USD $3197.160041
≥25 USD $3174.935492
≥50 USD $3152.865438
≥100 USD $3088.017077
≥500 USD $2867.239622
Inventory: 1165
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Phase Noise -110 dBc/Hz
Secondary Attributes Triple Outputs (Divide by 2, Divide by 4, Standard)
RF Type General Purpose
Control Voltage-Min 2V
Control Voltage-Max 13V
Output Power 4dBm
Supply Current-Max 300mA
Oscillator Type VOLTAGE CONTROLLED OSCILLATOR
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.25V
Operating Temperature (Min) -40°C
Physical Dimension 5.1mm x 5.1mm x 1.0mm
Operating Temperature (Max) 85°C
Function VCO
Base Part Number HMC529
Frequency 12.4GHz~13.4GHz
Reach Compliance Code not_compliant
Supply Voltage 5V
Additional Feature TAPE AND REEL
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Physical
Number of Pins 32
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
