HMC529LP5E
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MMIC AMP VCO HBT 2OUT 32-QFN
PDF
/
Buying Options
Total Price: USD $41.78
Unit Price: USD $41.7824
≥1 USD $41.7824
≥10 USD $38.95848
≥100 USD $36.134912
≥500 USD $33.876656
≥1000 USD $31.618189
Inventory: 82
Minimum: 1
-
+
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
ECCN Code 3A001.A.11.B
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Supply Voltage 5V
Frequency 12.4GHz~13.4GHz
Base Part Number HMC529
Function VCO
Physical Dimension 5.1mm x 5.1mm x 1.0mm
Operating Supply Voltage 5V
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Oscillator Type VOLTAGE CONTROLLED OSCILLATOR
Supply Current-Max 300mA
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Phase Noise -110 dBc/Hz
Secondary Attributes Triple Outputs (Divide by 2, Divide by 4, Standard)
RF Type General Purpose
Control Voltage-Min 2V
Control Voltage-Max 13V
Output Power 4dBm
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Factory Lead Time 8 Weeks
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 5.1mm
Length 5.1mm
Height 1mm
