HMC432 image
Favorite
HMC432 image
Favorite
RoHS
/
Package SOT-23-6
Category RF/IF and RFID / RF Misc ICs and Modules
Description Prescaler InGaP HBT Divide-by-2 SMT, DC - 8 GHz
PDF
/
Buying Options
Total Price: USD $17.36
Unit Price: USD $17.3624
≥1 USD $17.3624
≥10 USD $16.03008
≥100 USD $14.694592
≥500 USD $13.581304
Inventory: 117
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC

Dimensions

Length 2.9mm
Height Seated (Max) 1.45mm

Technical

Number of Data/Clock Inputs 1
Secondary Attributes Divide by 2
fmax-Min 8000 MHz
RF Type General Purpose
Output Polarity TRUE
Family 432
Operating Supply Current 42mA
Min Supply Voltage 2.7V
Max Supply Voltage 3.3V
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3V
Qualification Status Not Qualified
Function Prescaler
Base Part Number HMC432
Time@Peak Reflow Temperature-Max (s) 30
Frequency 0Hz~8GHz
Reach Compliance Code not_compliant
Terminal Pitch 0.95mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code 3A001.A.11.B
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Packaging Strip

Physical

Number of Pins 6
Package / Case SOT-23-6
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Lead, Tin

Supply Chain

Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
