HMC416LP4E
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC MMIC AMP VCO BUFFER 24-QFN
PDF
/
Buying Options
Total Price: USD $18.22
Unit Price: USD $18.216
≥1 USD $18.216
≥10 USD $16.48152
≥100 USD $15.180704
≥500 USD $13.879536
≥1000 USD $13.012032
≥3000 USD $12.144563
Inventory: 110
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 4.1mm
Length 4.1mm
Height 1mm
Technical
Characteristic Impedance 50Ohm
RF Type General Purpose
VSWR-Max 2
RF/Microwave Device Type NARROW BAND LOW POWER
Logic Function Buffer
Min Supply Voltage 2.75V
Max Supply Voltage 3.25V
Operating Supply Voltage 3V
Function VCO, Buffer Amp
Base Part Number HMC416
Frequency 2.75GHz~3GHz
Construction COMPONENT
HTS Code 8542.39.00.01
Additional Feature LOW NOISE
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Physical
Number of Pins 24
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 8 Weeks
