HMC394LP4ETR
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Prescaler program 5-Bit Counter SMT, DC - 2.2 GHz
PDF
/
Buying Options
Total Price: USD $31.48
Unit Price: USD $31.4776
≥1 USD $31.4776
≥10 USD $29.0532
≥100 USD $26.631968
≥500 USD $24.614392
≥1000 USD $23.403882
Inventory: 201
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1mm
Technical
Number of Data/Clock Inputs 1
fmax-Min 2200 MHz
RF Type General Purpose
Logic IC Type PRESCALER
Output Polarity COMPLEMENTARY
Family 394
Operating Supply Current 194mA
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade OTHER
Operating Supply Voltage 5V
Qualification Status Not Qualified
Function Counter
Base Part Number HMC394
Time@Peak Reflow Temperature-Max (s) 30
Frequency 0Hz~2.2GHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Cut Tape (CT)
Physical
Weight 928.191737mg
Number of Pins 24
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
