HMC156AC8 image
Favorite
HMC156AC8 image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Misc ICs and Modules
Description Signal Conditioning Passive SMT Freq. Doubler0.7 - 2.4 GHz
PDF
/
Inventory: 6079
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Conversion Loss-Max 20 dB
Input Power-Max (CW) 27dBm
RF Type VSAT, DBS
Insertion Loss (dB) 15 dB
Impedance 50Ohm
Function Doubler
Base Part Number HMC156
Frequency 700MHz~2.4GHz
Construction COMPONENT
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Strip

Physical

Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount

Supply Chain

Lifecycle Status OBSOLETE (Last Updated: 4 days ago)
