HMC1096LP3E
RoHS
RoHS compliant
RoHS compliantPackage 16-VQFN Exposed Pad, CSP
Category RF/IF and RFID / RF Misc ICs and Modules
Description
ANALOG DEVICES HMC1096LP3E GaAs pHEMT MMIC x2 Active Frequency Multiplier, 3.8-5.6 GHz Output
PDF
/
Buying Options
Total Price: USD $42.83
Unit Price: USD $42.8296
≥1 USD $42.8296
≥10 USD $39.93968
≥100 USD $37.045184
≥500 USD $34.729904
≥1000 USD $32.414554
Inventory: 36
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Characteristic Impedance 50Ohm
Input Power-Max (CW) 5dBm
RF Type VSAT
RF/Microwave Device Type FREQUENCY DOUBLER
Max Supply Voltage 5V
Function Frequency Multiplier
Base Part Number HMC1096
Frequency 3.8GHz~5.6GHz
Construction COMPONENT
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Physical
Number of Pins 16
Package / Case 16-VQFN Exposed Pad, CSP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
