HMC1065LP4E
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Up/Down Conv Mixer 3V 34000MHz 24-Pin QFN Bulk
PDF
/
Buying Options
Total Price: USD $58.82
Unit Price: USD $58.8192
≥1 USD $58.8192
≥10 USD $54.8416
≥100 USD $50.867872
≥500 USD $47.688608
Inventory: 53
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
LO Tunable YES
Characteristic Impedance 50Ohm
RF/Microwave Device Type DOWN CONVERTER
Gain 12 dB
Operating Supply Current 90mA
Operating Supply Voltage 3V
Function Downconverter
Base Part Number HMC1065
Frequency 27GHz~34GHz
Construction COMPONENT
Max Power Dissipation 1.66W
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Physical
Weight 928.191737mg
Number of Pins 24
Package / Case 24-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 8 Weeks
