ADL5920ACPZ
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description
DIRECTIONAL BRIDGE W/ INTEG. RMS
PDF
/
Buying Options
Total Price: USD $32.79
Unit Price: USD $32.7888
≥1 USD $32.7888
≥10 USD $30.59144
≥100 USD $29.308928
≥500 USD $26.561374
≥1000 USD $25.645418
Inventory: 76
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 32-WFQFN Exposed Pad
Surface Mount YES
Technical
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 9kHz~7GHz
JESD-30 Code S-XQCC-N32
Function Power Detector
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 5.1V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 4.9V
Analog IC - Other Type ANALOG CIRCUIT
RF Type General Purpose
Secondary Attributes 4.9V ~ 5.1V Supply
Dimensions
Height Seated (Max) 0.8mm
Length 5mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
