ADF5904WCCPZ
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad, CSP
Category RF/IF and RFID / RF Misc ICs and Modules
Description
IC 4 CHANNEL MMIC 24GHZ
PDF
/
Buying Options
Total Price: USD $40.63
Unit Price: USD $40.6296
≥1 USD $40.6296
≥10 USD $37.90864
≥100 USD $36.320064
≥500 USD $32.914974
≥1000 USD $31.779942
Inventory: 127
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
RF Type Radar
Telecom IC Type TELECOM CIRCUIT
Min Supply Voltage 3.135V
Max Supply Voltage 3.465V
Temperature Grade INDUSTRIAL
Function Downconverter
Base Part Number ADF5904
Time@Peak Reflow Temperature-Max (s) 30
Frequency 24GHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series Automotive
Packaging Tray
Physical
Number of Pins 32
Package / Case 32-WFQFN Exposed Pad, CSP
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
