AD8284WCSVZ

Analog Devices Inc.
RoHS
RoHS RoHS compliant
Package 64-TQFP Exposed Pad
Category RF/IF and RFID / RF Misc ICs and Modules
Description RF Front End 4-Ch Muxed Input Radar Analog Front End
PDF
/
Buying Options
Total Price: USD $23
Unit Price: USD $23.0032
≥1 USD $23.0032
≥10 USD $21.21504
≥100 USD $20.261824
≥500 USD $18.11656
≥1000 USD $17.282285
≥3000 USD $16.447957
Inventory: 49
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 10.2mm
Length 10.2mm
Height 1.05mm

Technical

Secondary Attributes Automotive Systems
RF Type Radar
Input Capacitance 1.5pF
Number of A/D Converters 1
Settling Time 80 ns
Power Supply Rejection Ratio (PSRR) 90dB
Sampling Rate 80 Msps
Resolution 1.5 B
Gain Bandwidth Product 30MHz
Bandwidth 15MHz
Input Offset Voltage (Vos) 2mV
Common Mode Rejection Ratio 100 dB
Slew Rate 450 V/μs
Quiescent Current 7.5mA
Operating Supply Current 15mA
Min Supply Voltage 1.7V
Max Supply Voltage 3.5V
Interface SPI, Serial
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3.3V
Function Front End
Base Part Number AD8284
Time@Peak Reflow Temperature-Max (s) 30
Frequency 15MHz
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type General Purpose
ECCN Code EAR99
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
Series Automotive
Packaging Tray

Physical

Weight 360.605934mg
Number of Pins 64
Package / Case 64-TQFP Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin

Supply Chain

Lifecycle Status PRODUCTION (Last Updated: 1 week ago)
Factory Lead Time 8 Weeks
