AD630SD/883B
RoHS
/
Package 20-CDIP (0.300, 7.62mm)
Category RF/IF and RFID / RF Misc ICs and Modules
Description
Balanced Mod/Dmod 20-Pin SBCDIP
PDF
/
Buying Options
Total Price: USD $154.89
Unit Price: USD $154.8918
≥1 USD $154.8918
≥10 USD $149.72855
≥100 USD $134.23975
Inventory: 708
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Length 25.4mm
Height Seated (Max) 5.08mm
Technical
RF Type General Purpose
Consumer IC Type CONSUMER CIRCUIT
Screening Level MIL-STD-883 Class B
Max Supply Current 5mA
Nominal Supply Current 5mA
Operating Supply Current 5mA
Supply Voltage-Min (Vsup) 5V
Temperature Grade MILITARY
Operating Supply Voltage 16.5V
Operating Temperature (Min) -55°C
Operating Temperature (Max) 125°C
Function Modulator/Demodulator
Base Part Number AD630
Frequency 0Hz~2MHz
Terminal Pitch 2.54mm
Terminal Position DUAL
Max Power Dissipation 600mW
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code 5A991.A
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Physical
Number of Pins 20
Package / Case 20-CDIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Lead, Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 10 Weeks
